Khoom taw qhia:
ZJC lub tshuab nqus tsev roj purifier txais cov txheej txheem kev sib cais siab tshaj plaws thiab PLC tsis siv neeg tswj tshuab, Nws tuaj yeem tshem tawm cov dej dawb, dej yaj, roj, impurities thiab lwm yam khoom siv phom sij kom huv si, txhawm rau txhim kho cov roj zoo, rov qab viscosity, flash point thiab lwm yam kev ua yeeb yam ntawm cov roj lubricating lossis turbine roj. Lub tshuab no siv coalescence cais lim caij, integrates zoo lim, high efficiency Anti-emulsification thiab lub cev qhuav dej rau hauv ib lub cev. Lawv tuaj yeem tshem tawm cov dej loj yam tsis muaj cua sov, ua kom lub cev qhuav dej ceev tshaj plaws hauv tsev tam sim no. Lub tshuab no tuaj yeem sib cais dej sai sai ntawm cov roj uas txawm tias muaj ib nrab dej, kom ua kom huv ntawm NAS6 qib.
Nta:
1.ZJC series lub tshuab nqus tsev roj purifier txais cov roj dej tshwj xeeb uas yuav tsum tsis muaj cua sov muab ntau tshaj 20 lub sij hawm dehydrating efficiency dua lwm hom purifier.
2. Raws li tsis muaj cua sov yuav tsum tau, cov additives nyob rau hauv cov roj yog zoo tiv thaiv los ntawm degradation los yog deterioration.
3. Yooj yim-rau- ua haujlwm, dej tuaj yeem tawm hauv online tau yam tsis muaj kev tuav tes.
4. Cov nqi ua haujlwm qis, 20 feem pua -40 feem pua qis dua lub tshuab nqus tsev purifier, centrifugal purifier thiab lim xovxwm.
5. ZJC Series Purifier suav nrog kev ua kom pom tseeb, ua kom lub cev qhuav dej thiab lub tshuab nqus tsev evaporation thiab automation zoo li.
6. Nyob rau hauv txoj kev ntawm kev tswj tsis siv neeg, siv PLC programmable maub los txhim khu kev qha thiab tsis yog - hluav taws xob tshawb nrhiav tshuab, uas tuaj yeem ntes tau ntau yam khoom siv ua haujlwm, nrog kev ua haujlwm tsis siv neeg, kev tswj qhov kub thiab txias, kev tiv thaiv siab, tiv thaiv { {2}}kev ua haujlwm thiab lwm yam haujlwm; Zoo meej rau tus kheej- kuaj kev ua haujlwm ntawm lub cev, muaj zog tiv thaiv- muaj peev xwm cuam tshuam, thiab teeb tsa RS232 kev sib txuas lus sib txuas, txhawm rau pab txhawb kev sib txuas hauv computer kom ua tiav cov chaw taws teeb tswj thiab tswj; Teem ua ntej tes- tuav cov chaw taws teeb tswj interface uas tso cai rau tsis muaj neeg saib xyuas.
Qhov zoo:
Lub tshuab nqus tsev roj purifier yog Nrog cov thev naus laus zis thev naus laus zis sib cais thiab PLC tsis siv neeg tswj tshuab, lub tshuab tuaj yeem sib cais dej sai sai ntawm cov roj uas txawm tias muaj ib nrab dej, tsim kom muaj lub cev qhuav dej sai tshaj plaws hauv tsev. PLC programmable maub los uas muaj kev ntseeg siab heev thiab tsis yog -cov cuab yeej hluav taws xob tshawb pom ua rau lub tshuab tuaj yeem ua haujlwm yam tsis muaj kev tuav haujlwm.
Specification:
Yam khoom | Chav tsev | ZJC-10 | ZJC-20 | ZJC-30 | ZJC-50 | ZJC-75 | ZJC-100 | ZJC-150 | ZJC-200 |
Tus nqi ntws | L/H | 600 | 1200 | 1800 | 3000 | 4500 | 6000 | 9000 | 12000 |
Nqus degree | Mpa | -0.06 - -0.096 | |||||||
Ua hauj lwm siab | Mpa | Tsawg dua lossis sib npaug rau 0.3 | |||||||
txhaum dawb | H | Ntau dua lossis sib npaug li 4000 | |||||||
Lub sijhawm ua haujlwm tsis tu ncua | H | Ntau tshaj los yog sib npaug rau 150 | |||||||
Ua haujlwm kub | degree | 40 - 70 | |||||||
Lub zog cua sov | kW | 15 | 18 | 30 | 45 | 60 | 72 | 72 | 84 |
Tag Nrho Lub Zog | kW | 17 | 20 | 33 | 49 | 66 | 79 | 81 | 97 |
Txoj kab uas hla ntawm qhov hluav taws xob inlet | DN | 25 | 25 | 25 | 32 | 42 | 42 | 50 | 50 |
hnyav | Kg | 500 | 530 | 570 | 780 | 800 | 960 | 1050 | 1550 |
Dimension (mm) | L | 1300 | 1350 | 1450 | 1500 | 1500 | 1800 | 1800 | 1800 |
W | 1000 | 1000 | 1100 | 1150 | 1000 | 1500 | 1650 | 1500 | |
H | 1450 | 1450 | 1500 | 1650 | 1750 | 1800 | 1900 | 2000 | |
Roj index tom qab kho | |||||||||
Cov ntsiab lus dej | 80ppm ua | ||||||||
Cov ntsiab lus roj | Tsawg dua lossis sib npaug rau 0.1 feem pua | ||||||||
kev huv | Less than or equal to 5µm（or as per requirement） | ||||||||
Tus nqi Demulsification | Tsawg dua los yog sib npaug li 10 min | ||||||||
Ntim Shipping
1. Pob: ntoo rooj
2. Chaw nres nkoj ntawm Chaw thau khoom: Chongqing, Shanghai lossis lwm qhov chaw nres nkoj loj ntawm Tuam Tshoj.
3. Txoj kev xa khoom: los ntawm hiav txwv, los ntawm huab cua, tsheb thauj khoom, los ntawm kev nthuav qhia, kev thauj mus los ua ke.
4. Lub Sij Hawm Lub Sij Hawm: Nws txawv nrog cov khoom lag luam, kev txiav txim kom muaj nuj nqis, tshwj xeeb xav tau thiab lwm yam. Feem ntau peb lub tshuab xa khoom loj yog nyob ib ncig ntawm 10 20 hnub; Cov khoom siv kuaj lossis ntsuas hnub xa khoom yog nyob ib ncig ntawm 510 hnub. Qee cov khoom muaj Tshuag, tiv tauj peb txhua lub sijhawm kom tau txais cov ntaub ntawv ntxiv.
Cim npe nrov: Lub tshuab nqus tsev roj purifier, Tuam Tshoj, lwm tus neeg, manufacturers, customized, lag luam wholesale, nqe
