Product Description
Turbine roj lim tshuab feem ntau yog siv los kho cov roj turbine tsis tsim nyog, tshwj xeeb tshaj yog tsim rau cov roj turbine hnyav, uas tuaj yeem tshem tawm cov dej noo, roj thiab impurities hauv cov roj. Ua kom cov ntsuas zoo ntawm cov khoom siv roj ua tau raws li cov qauv roj tshiab kom ntseeg tau tias kev ua haujlwm nyab xeeb ntawm chav turbine. Lub tshuab no siv cov khoom siv tshwj xeeb polymer ua qhov nruab nrab, uas ua ke nrog demulsification, lub cev qhuav dej thiab tshem tawm impurity. Ua ke nrog lub tshuab nqus tsev sib cais, nws tuaj yeem online demulsification, lub cev qhuav dej, tshem tawm cov kua qaub, thiab tshem tawm impurity, kom cov roj turbid hnyav thiab emulsified ua kom pom tseeb. pob tshab. Turbine roj lim yog cov cuab yeej zoo tshaj plaws rau kev ua online ntawm cov roj turbine, tsis tshua muaj viscosity lubricating roj thiab roj hydraulic.
Khoom zoo:
1. Muaj peev xwm tshem tawm cov dej thiab tawg emulsification, nws yog ib qho yooj yim los cais cov dej ntau hauv cov roj, thiab nws kuj tseem yooj yim tshem tawm cov dej me me hauv cov roj. Cov roj ua kom pom tseeb thiab pob tshab.
2. The ability to filter impurities is strong. The automatic backwashing filter bag can remove a large amount of impurities in the oil. The large area and deep precision filter material can remove the fine particles in the oil. It can be used instead of the oil system cleaning device to make the oil with serious pollution. The system can also be restored to within the "Operating Turbine Oil Pollution Control Standards".
3. High degree ntawm automation, me me thiab lub teeb, muaj kev nyab xeeb thiab txhim khu kev qha. Lub tshuab lim roj turbine no siv cov khoom siv hluav taws xob infrared tsis siv neeg tswj, uas paub txog kev sib cais ntawm tus txiv neej- tshuab thiab ua rau kev ua haujlwm yooj yim dua thiab txhim khu kev qha.
Technical Parameter
|
Yam khoom |
chav tsev |
ZJC-10 |
ZJC-20 |
ZJC-30 |
ZJC-50 |
ZJC-75 |
ZJC-100 |
ZJC-150 |
ZJC-200 |
ZJC-300 |
||
|
Tus nqi ntws |
L/H |
600 |
1200 |
1800 |
3000 |
4500 |
6000 |
9000 |
12000 |
18000 |
||
|
Nqus degree |
Mpa |
-0.06 - -0.096 |
||||||||||
|
Ua hauj lwm siab |
Mpa |
Tsawg dua lossis sib npaug rau 0.3 |
||||||||||
|
txhaum dawb |
H |
Ntau dua lossis sib npaug li 4000 |
||||||||||
|
Lub sijhawm ua haujlwm tsis tu ncua |
H |
Ntau tshaj los yog sib npaug rau 150 |
||||||||||
|
Ua haujlwm kub |
degree |
40 - 70 |
||||||||||
|
Lub zog cua sov |
kW |
9 |
18 |
30 |
36 |
60 |
72 |
108 |
144 |
144 |
||
|
Tag Nrho Lub Zog |
kW |
11.5 |
17.5 |
33 |
39.5 |
66 |
79 |
115 |
153.5 |
154 |
||
|
Txoj kab uas hla ntawm inletoutlet |
DN |
25 |
25 |
25 |
32 |
42 |
42 |
50 |
50 |
50 |
||
|
hnyav |
Kg |
500 |
530 |
570 |
780 |
800 |
960 |
1050 |
1150 |
1350 |
||
|
Qhov ntev |
L |
mm |
1300 |
1350 |
1450 |
1500 |
1500 |
1800 |
1800 |
1800 |
2500 |
|
|
W |
mm |
1000 |
1000 |
1100 |
1150 |
1000 |
1500 |
1650 |
1500 |
1600 |
||
|
H |
mm |
1450 |
1450 |
1500 |
1650 |
1750 |
1800 |
1900 |
2000 |
2200 |
||
|
Roj index tom qab kho |
||||||||||||
|
Cov ntsiab lus dej |
80ppm ua |
|||||||||||
|
Cov ntsiab lus roj |
Tsawg dua lossis sib npaug rau 0.1 feem pua |
|||||||||||
|
kev huv |
Less than or equal to 5µm（or as per requirement） |
|||||||||||
|
Tus nqi Demulsification |
Tsawg dua los yog sib npaug li 10 min |
|||||||||||
Cov neeg ua haujlwm zoo
Tongrui Filtration Equipment tau txais ntau daim ntawv pov thawj patent, muab cov neeg siv khoom nrog ib qho - rau - ib qho kev txhawb nqa
Kev them nyiaj kom zoo dua
Them los ntawm T / T, L / C, Weston union, Paypal ...
Lub sij hawm xa tuaj:
12 hnub ua haujlwm yog tias nws nyob hauv Tshuag. Yog tias tsis nyob hauv Tshuag, ces 57 hnub ua haujlwm
Cov nqe lus shipping:
Los ntawm nkoj, tsheb, huab cua lossis lwm yam
Cim npe nrov: turbine roj lim tshuab, Tuam Tshoj, lwm tus neeg, manufacturers, customized, lag luam wholesale, nqe
