Cov ntaub ntawv yooj yim
ZJR yog ob theem siab nqus transformer roj purifier tshuab, uas muaj lub tshuab nqus tsev twj thiab cov hauv paus hniav twj tso kua mis. Peb tuaj yeem ua ntau lub peev xwm ntawm lub tshuab, thiab qhov tsawg tshaj plaws yog ZJR-30, 1800L / H, Qhov loj tshaj yog ntau tshaj 30,000L / H. Lub tshuab yog saws cov rustproof thiab ya raws zaj duab xis thiab ntoo rooj plaub. Peb tuaj yeem muab kev txiav txim tshwj xeeb rau koj, xws li lub ntsej muag lub ntsej muag, xim, qhov hnyav, qhov loj me, lim precision, lim cov lej, cov khoom seem, cov roj specification tester, thiab lwm yam.
Txoj cai ntawm kev ua haujlwm:
During high vacuum transformer oil purifier machine working, oil remove impurities by highly efficient specific filter. It use special personalized vacuum separator and its "layered filtration" high-precision filtering technologies, and use the "cavitations'" principle, and then the contact area of the oil in vacuum separator expanded a few hundred times than before. The "cavitations'" system let surface area of the oil evaporation become greater, and the Evaporation interface Update continuously so that increased volatilization of water and the regeneration of the oil in vacuum system by the greatest extent. The moisture can be quickly removed under the condition of the low temperature/ high vacuum/ large surface and at high pumping speed. Finally it been excreted from vacuum system.
Cov roj raug tshem tawm xim los ntawm decoloration regeneration system. Tom qab ntawd, cov roj kom zoo pom cov roj net yuav ntws los ntawm cov roj qhov hluav taws xob thiab ua kom tiav tag nrho cov txheej txheem ntawm kev pom.
Technical parameters
Index | Chav tsev | ZJR |
Flow peev | L/H | 180018,000 |
Lub tshuab nqus tsev ua haujlwm | MPa | -0.092--0.099 |
Ua hauj lwm siab | MPa | Tsawg dua lossis sib npaug rau 0.3 |
lub tshuab nqus tsev siab tshaj plaws | Pa | Tsawg dua los yog sib npaug li 50 |
Qhov kub thiab txias | degree | 45-80 |
Roj tawg voltage | kv ua | Ntau dua lossis sib npaug li 75 |
Cov ntsiab lus impurities | ua um | Tsawg dua lossis sib npaug li 3 Tsis muaj cov pa roj carbon dawb |
Dielectric poob | tgδ | Tsawg dua lossis sib npaug rau 0.005 |
Interfacial nro | mN／m | Ntau dua lossis sib npaug li 40 |
Cov ntsiab lus dej | PPM | Tsawg dua los yog sib npaug li 5 |
Cov ntsiab lus roj | ％ | Tsawg dua lossis sib npaug rau 0.1 |
Ua haujlwm nrov nrov | dB (A) | Tsawg dua los yog sib npaug li 75 |
Kev Tiv Thaiv Kev Ua Haujlwm
1. Thaum lub tshuab nqus tsev twj tso kua mis ua haujlwm, ua tib zoo saib cov roj teeb pom kev los ntawm cov roj cim (cov roj yuav tsum nyob rau ntawm cov roj cim kab). Thaum lub tshuab nqus tsev twj tso kua mis muaj roj thiab dej ntau, nws yuav tsum tau hloov raws sijhawm.
2. Thaum pom tias muaj dej ntau hauv lub qhov txias thaum lub sijhawm ua haujlwm, nws yuav tsum tau ntws tawm hauv lub sijhawm.
3. Nco ntsoov ua tib zoo saib xyuas qhov kev hloov pauv ntawm qhov ntsuas qhov ntsuas siab. Thaum lub siab ntau dua 0.3Mpa, lub lim yuav tsum tau muab ntxuav los yog hloov cov lim lim.
4. Cov ntxaij lim dej ntawm cov lim thawj thiab cov lim thib ob yuav tsum tau muab tshem tawm thiab ntxuav tas li kom huv si kom tsis txhob txhaws, ua rau cov roj tsis txaus lossis siab dhau.
5. Ua tib zoo saib seb lub suab nrov ntawm lub twj tso kua mis thiab lub cev muaj zog yog qhov qub thaum lub sijhawm ua haujlwm. Yog tias nws txawv txav, nws yuav tsum tau muab tshem tawm tam sim ntawd.
6. Thaum lub tshuab tsis siv, cov roj seem hauv lub tshuab roj yuav tsum tau ntws tawm los siv.
