Taw qhia
Muaj ntau hom kev qhia tshwj xeeb rau ZJC series siab nqus roj purifier. Tag nrho cov ntawm lawv tau txais tib lub tshuab cua sov, cov hauv paus ntsiab lus ntawm cov dej sib cais thiab lub tshuab nqus dej. Tus nqi ntws ntawm lub tshuab yog los ntawm 600 litre / teev mus rau 18,000litre / teev. Nws tsuas yog xav tau lub zog hluav taws xob rau ntawm - siv qhov chaw.
ZJC series roj purifier yog tsim los tshem tawm cov pa paug thiab ya raws hauv cov roj siv roj uas siv rau hauv chav turbine. Cov roj lim kuj tseem siv tau rau kev sau cov roj, cia tso tsheb hlau luam thiab lwm yam kev hloov roj.
Specification:
Yam khoom | Chav tsev | ZJC-10 | ZJC-20 | ZJC-30 | ZJC-50 | ZJC-75 | ZJC-100 | ZJC-150 | ZJC-200 |
Tus nqi ntws | L/H | 600 | 1200 | 1800 | 3000 | 4500 | 6000 | 9000 | 12000 |
Nqus degree | Mpa | -0.06 - -0.096 | |||||||
Ua hauj lwm siab | Mpa | Tsawg dua lossis sib npaug rau 0.3 | |||||||
txhaum dawb | H | Ntau dua lossis sib npaug li 4000 | |||||||
Lub sijhawm ua haujlwm tsis tu ncua | H | Ntau tshaj los yog sib npaug rau 150 | |||||||
Ua haujlwm kub | degree | 40 - 70 | |||||||
Lub zog cua sov | kW | 15 | 18 | 30 | 45 | 60 | 72 | 72 | 84 |
Tag Nrho Lub Zog | kW | 17 | 20 | 33 | 49 | 66 | 79 | 81 | 97 |
Txoj kab uas hla ntawm qhov hluav taws xob inlet | DN | 25 | 25 | 25 | 32 | 42 | 42 | 50 | 50 |
hnyav | Kg | 500 | 530 | 570 | 780 | 800 | 960 | 1050 | 1550 |
Dimension (mm) | L | 1300 | 1350 | 1450 | 1500 | 1500 | 1800 | 1800 | 1800 |
W | 1000 | 1000 | 1100 | 1150 | 1000 | 1500 | 1650 | 1500 | |
H | 1450 | 1450 | 1500 | 1650 | 1750 | 1800 | 1900 | 2000 | |
Roj index tom qab kho | |||||||||
Cov ntsiab lus dej | 80ppm ua | ||||||||
Cov ntsiab lus roj | Tsawg dua lossis sib npaug rau 0.1 feem pua | ||||||||
kev huv | Less than or equal to 5µm（or as per requirement） | ||||||||
Tus nqi Demulsification | Tsawg dua los yog sib npaug li 10 min | ||||||||
Txoj haujlwm ua haujlwm:
The high vacuum oil purifier is for kinds of turbine oil, hydraulic oil and ect. The used oil is mixed with catalyst in chemical treatment tank, then it is sent to distillation kettle to have it circulated and heated, while the temperature increasing, the oil gas is distilled out and cooled in to liquid through three stages cooling, they're separately stored in water, gasoline/diesel, light lube oil, heavy lube oil receivers. The noncondensable gas will be sent to the furnace of boiler to have it burned and discharged after pass through waste gas disposer to ensure "zero "discharge of waste gas, The residues can be utilized as fuel to avoid pollution from it.
Accessories:
(1) Siv roj tank (2) Ua ntej- lim (3) rhaub (4) Dej cais (5) Dej txais (6) Nqus cais tank (7) Roj twj tso kua mis (8) Roj twj tso kua mis (9) Fine lim (10) Lub tank huv huv (11) Ua npuas dej (12) Radiator (13) Lub tshuab nqus dej (14) Lub tshuab nqus tsev twj (15) Txias (16) Lub tshuab nqus dej (17) Qhov chaw tso pa tawm.
Kev xaiv hom:
1. The customers' request can be met by adopting PLC intelligent control, touch screen and dynamical display.
2. On line water tester muaj nyob.
3. Muaj nyob rau hauv kev xaiv mobile, immovable xaiv thiab trailer.
4. Roj purifier tuaj yeem ua rau hauv hermetical, canopy - npog, qhib thiab thav duab style.
5. tuaj yeem xaiv dej- lub tshuab nqus tsev twj tso kua mis.
Warranty thiab peb cov kev pabcuam:
(1) 100 feem pua cov khoom lag luam tshiab, peb siv sijhawm 12 lub hlis mus rau 24 lub hlis (ib qho kev puas tsuaj los ntawm tus neeg yuav khoom yuav tsis yog tus muag khoom lub luag haujlwm) lav zoo.
Peb qhov kev pabcuam:
peb muab kev pabcuam dawb, xws li:
1) kev pabcuam txawv tebchaw
2) Kev kho thiab hloov kev pabcuam, thaum tsim nyog
3) kev pabcuam nrhiav cov khoom rau 12 lub hlis, kev pabcuam lub neej
4) lub neej kev pabcuam kev pabcuam
5) cov neeg siv khoom qub muaj luv nqi ntau dua, lossis cov neeg siv khoom qhia lwm tus rau peb, uas muaj luv nqi ntau dua
